Home Relay & Sensor Protect ptc Power failure relay

Protect ptc Power failure relay

4 Pin 5a 10a 28VDC Sealed Protect ptc Power failure relay

  • Brand:

    Gangyuan
  • Item NO.:

    HRS3
  • Order(MOQ):

    1000pcs
  • Payment:

    100% T/T Before Production
  • Product Origin:

    Zhejiang, China (Mainland)
  • Color:

    black
  • Shipping Port:

    Ningbo/Shenzhen
  • Lead Time:

    7 Working Days after payment
  • Product Detail

4 Pin 5a 10a 28VDC Sealed Protect ptc Power failure relay

Product Description:

  • Microminiature relay
  • Dimensions: 15.6×10.6×11.8 (mm) High sensitivity
  • Contact: 1 Form C
  • Max. Switching capacity 3A



Contact Form

1 Form A, 1 Form C

Contact Material

Ag Alloy

Contact Rating

A: 10A 125VAC, 5A 250VAC/28VDC C: NO/NC: 5A/3A 250VAC/28VDC

Contact Resistance

Max. 100mΩ (6VDC 1A)





Load

Max. Switching Voltage

250VAC/28VDC



Max. Switching Current

10A



Max. Switching Power

1,250VA, 280W



Min. Switching Load

5VDC, 100mA



Life

Electrical

100,000 operations



Mechanical

10,000,000 operations



Insulation Resistance

Min. 1000MΩ 500VDC



Dielectric Strength

Between open contacts

1,000VAC, 1min



Between coil and contacts

A: 3,500VAC, 1 min C: 2,500VAC, 1 min

Operate Time

Max. 10ms

Release Time

Max. 5ms

Operating Temperature

-40℃ to +85

Humidity

35~95 RH, +40

Shock



Endurance

1,000m/s2

Resistance

Misoperation

100m/s2

Vibration



Endurance

10~55Hz, 1.5mm double amplitude

Resistance

Misoperation

10~55Hz, 1.5mm double amplitude

Weight

Approximately 6.0g





Dimension:
