Home Relay & Sensor 6 pin high voltage 24 v dc relay

6 pin high voltage 24 v dc relay

Wholesale mini Relay module 6 pin high voltage 24 v dc relay

  • Brand:

    Gangyuan
  • Item NO.:

    HRAH-S-DC12V
  • Order(MOQ):

    1000pcs
  • Payment:

    100% T/T Before Production
  • Product Origin:

    Zhejiang, China (Mainland)
  • Color:

    gray
  • Shipping Port:

    Ningbo/Shenzhen
  • Lead Time:

    7 Working Days after payment
  • Product Detail

Wholesale mini Relay module 6 pin high voltage 24 v dc relay



Product Description:



Product name

Relay

Contact Form

1 Form C

Contact Material

AuAg overlay

Contact Rating

1A 120VAC/24VDC

Contact Resistance

Max. 50mΩ (6VDC 0.1A)

Max. Switching Voltage

120VAC/30VDC

Max. Switching Current

2A

Mechanical

10,000,000 operations

Insulation Resistance

Min. 100MΩ 500VDC

Operating Temperature

-25℃ to +70℃



Dimension:
