Home Relay & Sensor 3 contact relay 12v 50a automotive

3 contact relay 12v 50a automotive

High Power Load auto relays 3 contact relay 12v 50a automotive

  • Brand:

    Gangyuan
  • Item NO.:

    CMA1
  • Order(MOQ):

    1000pcs
  • Payment:

    100% T/T Before Production
  • Product Origin:

    Zhejiang, China (Mainland)
  • Color:

    black
  • Shipping Port:

    Ningbo/Shenzhen
  • Lead Time:

    7 Working Days after payment
  • Product Detail

High Power Load auto relays 3 contact relay 12v 50a automotive

Product Description:

  • Dimensions: 19.0×15.5×15.8(mm)

  • Miniature automotive relay

  • High Switching capacity 20A Available in 3 contact configurations, 1 Form A, B and C

  • Applications: car alarm, central locking system, power windows,seat control, etc

Contact Form

1 Form A, 1 Form B, 1 Form C

Contact Material

Ag Alloy

Contact Rating

15A 14VDC Resistive (B, C) 20A 14VDC Resistive (A)

Contact Resistance

Max. 100mΩ (6VDC 1A)



Load

Max. Switching Voltage

75VDC



Max. Switching Current

20A



Max. Switching Power

280W



Life

Electrical

100,000 operations at nominal load



Mechanical

10,000,000 operations



Contact Form

1 Form A, 1 Form B, 1 Form C

Contact Material

Ag Alloy

Contact Rating

15A 14VDC Resistive (B, C) 20A 14VDC Resistive (A)

Contact Resistance

Max. 100mΩ (6VDC 1A)



Load

Max. Switching Voltage

75VDC



Max. Switching Current

20A



Max. Switching Power

280W



Life

Electrical

100,000 operations at nominal load



Mechanical

10,000,000 operations



Dimension:
