5VDC 10mA solid state relay

5VDC 10mA 4 channel 24 hours solid state relay time relay

Brand:
Gangyuan
Item NO.:
HRS1
Order(MOQ):
10pcs
Payment:
100% T/T Before Production
Product Origin:
Zhejiang, China (Mainland)
Color:
yellow
Shipping Port:
Ningbo/Shenzhen
Lead Time：
14 working days for payment

Product Detail

5VDC 10mA 4 channel 24 hours solid state relay time relay

Basic Information

Product name	Relay
Contact Form	1 Form C
Contact Material	AuAg overlay
Contact Rating	1A 120VAC/24VDC 3A 120VAC/24VDC
Contact Resistance	Max. 50mΩ (6VDC 0.1A)
Max. Switching Voltage	220VAC/30VDC
Max. Switching Current	3A
Mechanical	10,000,000 operations
Insulation Resistance	Min. 100MΩ 500VDC
Operating Temperature	-25℃ to +70℃

Dimension

arduino 5v relay.jpg

Tact Switch Using Attention

1．Please consult us when considering to wash tact switches

2．Please don’t immerse soldering flux into tact s

3．Please don’t paint soldering flux on the surface of switch terminals and other parts in PCB board

4．The second welding should be done after switches return to normal temperature

Our advantage

1. Excellent R&D team, clients design requests are welcome.

2. Experience of more then two decades in switch manufacturing.
3. Two thousands invention patents and 47 utility model patents.
4. Assembly process in 100,000 grade dust-free workshop.
5. Owing TS16949,ISO9001,ISO14001,OHSA18001 system.

Application

Tactile switch use for: Mini type portable equipment, PCB board, Digital products, Kitchen appliances, Communication products, white home appliance, black home appliance, small home appliance, Security products, Toys, Computers, body building apparatus, medical appliance;

act Tactile Switch
