Wenzhou Gangyuan Electronics Co.,Ltd.
Hot sales Gangyuan Illuminated miniature tactile switches
Brand:
GangyuanItem NO.:
KAN6811-0580COrder(MOQ):
3000pcsPayment:
EXWProduct Origin:
Zhejiang ,ChinaColor:
led in bule red white yellowShipping Port:
Shanghai ,ShenzhenLead Time：
7-10 working daysOutline (mm)
6.80mm x 6.80mmMounting Type
Through Holelllumination
llluminatedIP Rating
IP4XHot sales illuminated miniature tactile switches
Quick details:
Model Number:KAN6811-0580C
Type: DIP
Terminal: sliver plating
Soldering type: wave soldering
Salt Mist: 8h±1h
Operation life: 1,000,000 cycles
Certification: UL,ROHS,SGS
Damp proof tape: no
Protection Level: normal
Max. Current: 50mA
Max. Voltage: 12V
Package Type:
3000pcs/reel, 20 reel/carton, carton size: 44*34*34cm, GW: 111 KGS, N.W. 9.7 KGS
Leadtime :
MOQ or sample in 5-7 working days
Mass production: 10 working days
Certifications:
Factory certificate: TS16949,ISO9001,ISO14001,OHSA18001
Products: CE,ROHS, UL, REACH, ENEC, CQC,CCC
Supply Ability
200000 Piece/Pieces per Week
FAQ:
Q1: Where is your factory located ?
A:We have three factories locates in Wenzhou,Hubei and Shenzhen
Q2: Is free samples available ?
A: Sure
Q3:How to deal with the quality control ?
A: 1) Factories all passed the certificate of TS16949,ISO9001,ISO14001,OHSA18001
2) Supply kinds of tactile switch for famous brand such as SAMSUNG,LG,PANASONIC, MIDEA, HISENSE, SCHNEIDER, ARCADUAN,FLYCO, OMARON, CANON for more than 24 years.
3) The the defected rate of production can be controlled within less than 0.1 %. once problem happen, we will offer you problem solution within 8 hours once get complaint and deal with the problem at customer processline or online guide.
Your trust and satisfication are proofs of our switch quality assurance
Previous:
Right angle tact switch with ledNext:
tact switch led right angleIf you want to purchase switch products and need to know quotations, parameters or solutions, please leave us a message, and we will give you a satisfactory reply within 2 hours.
