SMD 2 position slide type dip switch

A DIP switch is a manual electric switch that is packaged with others in a group in a standard dual in-line package. The term may refer to each individual switch, or to the unit as a whole.

Brand:
Gangyuan
Item NO.:
BMHP02S-CG-3F-M
Order(MOQ):
1000
Payment:
T/T, Paypal full payment before produce
Product Origin:
ZheJiang China
Color:
Black, Metal
Shipping Port:
Ningbo/ Shenzhen
Lead Time：
7-10 working days depends on actual orde

Outline (mm)
4.04mm x 5.40mm
Mounting Type
Surface Mount
lllumination
Non-llluminated
IP Rating
No IP Rating

Product Detail

Slide Type DIP switches, Including: Normally Open (NO), which means to disconnect its default position from the circuit, and actuate the switch to complete the operation again. Normally closed (NC), which means that the actuation switch will open contact with the circuit instead of closing the circuit.

Product Description

Product Name	SMD Dip switch
Position	2 ways
Life cycle	1000 steps
Operating force	Max 1000gf
Contact resistance	100mΩ Max
Insulation resistance	100MΩ Min
Switch Capacitance	Max 5PF

Drawing

Dip switch working principle

Each key of the DIP switch has two pins on the top and bottom of the back. Turn it to the ON side, and the two pins on the bottom will be turned on; otherwise, it will be turned off. These four keys are independent and not related to each other. Such components are mostly used for binary coding. There are 16 kinds of codes in total, which are used to control a wide range of types. According to different products and designs, the ways of using DIP switches are also different.

Application

All types of DIP switch are widely deployed across various industries and applications today, including such uses as:
1. Data processing, communication
2.Remote control
3. Anti-theft automatic alarm system
4.Air shower room
5.Air conditioning control panel
6. Train model
7. PC expansion cards
8. Arcade machines
9. Automatic garage doors

FAQ

1. Q: Are you switch manufacture/ factory? Location?
A: Yes, three palnts located in Shenzhen , Zhejiang, Hubei province.

2. Q: Do you have sales branch or sales representative office?
A: Yes. Sales branch: Shenzhen、HongKong、TaiWan、Singapore.

Sales representative office: Beijing、Shanghai、Guangzhou、Wuhan、Huizhou、Korea、Malaysia、Brazil.

3. Q: Can I get free sample before placing an order ? MOQ?
A: Yes, free samples will get ready within 3~5 days. Generally, MOQ is 1,000pcs.

4. Q: What about the delivery time?
A: Stable delivery. 7-15 working days.

5. Q: What about terms of payment ?
A: T/T, L/C, Paypal, Cash etc.

6. Q: Can you customize products according to the design drawing?
A: We have independent R&D center in Shezhen, ODM/OME project is welcome.

7. Q: Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.
