Wenzhou Gangyuan Electronics Co.,Ltd.
High quality 2.54mm 6pin 4way piano type DIP switch 25mA/24VDC red color switch
Brand:
GangyuanItem NO.:
DPL-03-VOrder(MOQ):
50 pcsPayment:
T/TProduct Origin:
zhejiang/shenzhenColor:
redShipping Port:
ningbo or shenzhenLead Time：
3 Working Days after payment
High quality 2.54mm 6pin 4way piano type DIP switch 25mA/24VDC red color switch
Basic Information
| Non-Switching Rating | 100mA 50VDC |
| Switch Rating | 25mA 24VDC |
| Circuit | Single Pole Single Throw |
| Contact Resistance | 50mA max at initial |
| Operating Temp. | -20℃+ 70℃ |
| Operating force | ≤9.8N |
| Mechanical life | 2,000 operation per switch |
| Stroke |
2.0mm |
Dimension
Tact Switch Using Attention
1．Please consult us when considering to wash tact switches2．Please don’t immerse soldering flux into tact switches
3．Please don’t paint soldering flux on the surface of switch terminals and other parts in PCB board
4．The second welding should be done after switches return to normal temperature
Our advantage
1. Excellent R&D team, clients design requests are welcome.
2. Experience of more then
two decades in switch manufacturing.
3. Two thousands invention patents and 47 utility model patents.
4. Assembly process in 100,000 grade dust-free workshop.
5. Owing TS16949,ISO9001,ISO14001,OHSA18001 system.
Application
Tactile switch use for: Mini type portable equipment, PCB board, Digital products, Kitchen appliances, Communication products, white home appliance, black home appliance, small home appliance, Security products, Toys, Computers, body building apparatus, medical appliance;
Previous:
dip switch 6 pinNext:
3 Pin SPST Electronic red DIP SwitchIf you want to purchase switch products and need to know quotations, parameters or solutions, please leave us a message, and we will give you a satisfactory reply within 2 hours.
