cherry high sensitive micro switch 125V 3A solder connect
Brand:
GangyuanItem NO.:
KW3-02P-30Order(MOQ):
1000pcsPayment:
100% T/T Before ProductionProduct Origin:
Zhejiang, China (Mainland)Color:
black and whiteShipping Port:
Ningbo/ShenzhenLead Time：
7 Working Days after paymentOutline (mm)
12.80mm x 6.60mmMounting Type
Through Holelllumination
Non-llluminatedIP Rating
IP4X
Product Description:
| Rating | 3A 125VAC | Voltage | DC 12V-14V |
| Contact Resistance | ≤500mΩ | Insulation Resistance | ≥100MΩ |
| Operating Force | 30±15gf | Soldering Temperature | 235±5cc 5s |
| Dielectric Withstanding Voltage | 500V AC 1Min | Life Time | 10000 Cycles |
Dimension:
