tactile switch with rgb led

7x7mm SMD tact high illuminated tactile switch with rgb led

Brand:
Gangyuan
Item NO.:
KAN0713
Order(MOQ):
50 pcs
Payment:
T/T
Product Origin:
zhejiang/shenzhen
Color:
black and white
Shipping Port:
ningbo or shenzhen
Lead Time：
3 Working Days after payment

Outline (mm)
6.80mm x 6.80mm
Mounting Type
Through Hole
lllumination
llluminated
IP Rating
IP4X

Product Detail

7x7mm SMD tact high illuminated tactile switch with rgb led

Basic Information

Model No.:	KAN0713
Dimension:	6*6mm
Operating force:	260gf±50gf
Life cycles:	500,000 times
DC rating:	12V DC, 50mA (effective value)
Salt mist:	8h±1h
Feature:	illuminated Tact Switch

Dimension

led in combination with tactile switch.jpg

led tactile switches.jpg

Tact Switch Using Attention

1．Please consult us when considering to wash tact switches

2．Please don’t immerse soldering flux into tact switches

3．Please don’t paint soldering flux on the surface of switch terminals and other parts in PCB board

4．The second welding should be done after switches return to normal temperature

Our advantage

1. Excellent R&D team, clients design requests are welcome.

2. Experience of more then two decades in switch manufacturing.
3. Two thousands invention patents and 47 utility model patents.
4. Assembly process in 100,000 grade dust-free workshop.
5. Owing TS16949,ISO9001,ISO14001,OHSA18001 system.

Application

Tactile switch use for: Mini type portable equipment, PCB board, Digital products, Kitchen appliances, Communication products, white home appliance, black home appliance, small home appliance, Security products, Toys, Computers, body building apparatus, medical appliance;

act Tactile Switch
